LED Driver 350mA 18W dimmable
Item No. EGDIM350/18W
|EG-Nr. 2737
This LED driver with constant output current is suitable for operating
,
and
. If there are several LEDs, these are connected in series to the LED driver.
| Power | 18W |
|---|---|
| Output current | 350mA |
| Dimming type | Leading +/or trailing edge |
| Protection | IP20 |
| Dimensions | 113x44x28mm |
| ELDAS®-Nr | 919 391 629 |
| Input voltage | 220-240V |
| Output voltage | 15-52V |
| Rated power | 5.25-18W |
| Dimmer | L-C |
| Ambient temperature | max.50°C |
| Housing temperature | max.90°C |
| Dimmer types | L Triac, C IGBT |
available from stock
Downloads
Description
This LED driver with constant output current is suitable for operating
,
and
. If there are several LEDs, these are connected in series to the LED driver.
