LED Driver ECOdrive 150-1400mA 30W DALI-2 DT6
Item No. EC0360A
|EG-Nr. 11349
The ECOdrive constant current driver (150-1400mA) with DALI 2 (DT6) is ideal for compact LED luminaires. The LED driver can be set to 1 mA accuracy via the Ledcode interface. The dimming curve and minimum dimming level can also be configured. The power supply dims smoothly with Hybrid Hydra Drive technology and optimal flicker performance. This makes the power supply suitable for HD TV studios or other applications with cameras. The Toolbox Pro (item number
) is required for programming.
| Power | 30W |
|---|---|
| Output current | LEDcode adjustable |
| Dimming type | DALI, DALI 2 |
| HD TV camera-compatible | Yes |
| Dimensions | 210x40x34mm |
| Brand | eldoLED |
| mA default | 350mA |
| Input voltage | 120-250V AC |
| Output voltage | 2-55Vdc |
available from stock
